Espace - LED 52" Ceiling Fan

F690L-ORB/MM Minka-Aire®
NOTIFY ME
Description

52" 5-Blade LED Ceiling Fan in Oil Rubbed Bronze Finish with Medium Maple Blades and Etched Opal Glass

Available Finish: Oil Rubbed Bronze

PRODUCT FAMILY

Espace by Minka-Aire®

F690L-BN/SL
Espace - LED 52" Ceiling Fan

F690L-BN/SL Minka-Aire®

F690L-WH
Espace - LED 52" Ceiling Fan

F690L-WH Minka-Aire®

F690L-ORB/MM
Espace - LED 52" Ceiling Fan

F690L-ORB/MM Minka-Aire®

F690L-CL
Espace - LED 52" Ceiling Fan

F690L-CL Minka-Aire®

Espace - LED 52" Ceiling Fan

SKU: F690L-ORB/MM
Brand: Minka-Aire®
Finish: Oil Rubbed Bronze

Measurements

Blade Material: PLYWOOD
Blade Sweep: 52
Blade Pitch: 14 DEGREES
Downrod 1: 6
Power: AC
Motor Size: AC 172 X 17 MM

Control Method

Control Type: FULL FUNCTION HAND HELD REMOTE
Reverse Capable: Yes

Lamping

Light Kit: Yes
Light Kit Description: 18W LED BULB INCLUDED
Bulb: LED
Bulb/LED Included: Yes
Socket Type: LED MODULE
Max Wattage: 18
Dimmable: Y

Shade

Shade Finish: ETCHED OPAL
Shade Qty: 1

Low Speed

RPM: 59
Amps: 0.31
Watts: 11.76
CFM: 1744.0

High Speed

RPM: 161
Amps: 0.58
Watts: 70.01
CFM: 5075.0
